KAZ Circuit has been operating as a manufacturer of PCB&PCBA since 2007. specialized in quick-turn manufacturing of prototypes and small to middle volume series of rigid, flex, rigid-flex and multilayer boards.
as well as aluminium substrate circuit board.we have a strong strength on fabrication of Roger board, MEGTRON MATERIAL board and 2&3 steps HDI boards and etc.
Beside with six SMT production lines and 2 DIP lines.we provide one-stop service to our customers as well.
Packing:Carton;P/P,Anti-static Bag.
2. PCB&PCBA Technical capability
| SMT | Position accuracy:20 um |
| Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP |
| Max. component height::25mm |
| Max. PCB size:680×500mm |
| Min. PCB size:no limited |
| PCB thickness:0.3 to 6mm |
| PCB weight:3KG |
| Wave-Solder | Max. PCB width:450mm |
| Min. PCB width: no limited |
| Component height:Top 120mm/Bot 15mm |
| Sweat-Solder | Metal type :part, whole, inlay, sidestep |
| Metal material:Copper , Aluminum |
| Surface Finish:plating Au, plating sliver , plating Sn |
| Air bladder rate:less than20% |
| Press-fit | Press range:0-50KN |
| Max. PCB size:800X600mm |
| Testing | ICT,Probe flying,burn-in,function test,temperature cycling |
2. PCBA Pictures
Detailed Informations:
4 Layers FR4 PCB, Electronic Circuit Board Assembly& Multilayer-PCBA Assembly
1. Features
1.Surface Mount PCB assembly (Both rigid PCB, flexible PCB);FR4 Material, Meet 94V0 standard
2.One Stop OEM Service,&PCBA contract manufacturing:
3.Electronic contract manufacturing service
4.Through hole assembly/DIP assembly;
5.Bonding assembly;
6.Final assembly;
7.Full Turnkey Box Build
8.Mechanical / electrical assembly
9.Supply Chain Management/Components procurement
10.PCB fabrication;
11.Technical support/ ODM service
12. Surface treament:OSP, ENIG,Lead Free HASL, Environmental Protection
13. UL, CE, ROHS Compliant
14. Shipping By DHL,UPS, TNT, EMS or Customer requirement
15.Anti-static bag
2. PCBA Technical capability
| SMT | Position accuracy:20 um |
| Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP |
| Max. component height::25mm |
| Max. PCB size:680×500mm |
| Min. PCB size:no limited |
| PCB thickness:0.3 to 6mm |
| PCB weight:3KG |
| Wave-Solder | Max. PCB width:450mm |
| Min. PCB width: no limited |
| Component height:Top 120mm/Bot 15mm |
| Sweat-Solder | Metal type :part, whole, inlay, sidestep |
| Metal material:Copper , Aluminum |
| Surface Finish:plating Au, plating sliver , plating Sn |
| Air bladder rate:less than20% |
| Press-fit | Press range:0-50KN |
| Max. PCB size:800X600mm |
| Testing | ICT,Probe flying,burn-in,function test,temperature cycling |
